Short Description:

24v 18ah 18650 rechargeable Lithium Ion battery pack
Model No.: SSL-IFR7S8PE22
Introduction:24V 25.2V 18AH lithium ion battery pack for kid motorcycle, toy car,lead acid replacement battery,E bike,electric scooter bicycle

Send email to us Download as PDF

Tech Specs & Features

Product Video

FAQ

Advantages

SOSLLI 24V 18000mAh 7S6P 18650 rechargeable lithium ion battery pack:

No.	Item		Specification	Remarks
1	Brand Name		SOSLLI or OEM
2	Model NO.		SSL-ICR186507S8P262
3	Normilar Capacity		17600mAh	0.2 C₅A discharge
4	Normilar Voltage		22.2V
5	Discharge Voltage (Min.)		16.5V
6	Charging Voltage (Max.)		25.2V
7	Charging Current (std.)		0.2 C₅A
8	Discharging Current (Max. continue)		1 C₅A
9	Discharging Current (Max. temporary)		2 C₅A
10	Charging Temperature & Humidity		0℃ ~ +45℃ 45~85%RH
11	Discharging Temperature & Humidity		-20℃ ~ +60℃ 45~85%RH
12	Battery storage and transportation environment temperature & humidity ranges	Min. 1 month	-20℃ ~ +60℃ 45~85%RH
		Min. 3 months	-20℃ ~ +45℃ 45~85%RH
		Min. 12 months	-20℃ ~ +25℃ 45~85%RH
13	Battery Type		Li-ion battery 18650 2000mAh
14	Internal Impedance
15	Protection Fuctions		Over charge, Over discharge, Over load, Short Circuit
16	Size			Recommend or Customize
17	Weight		Approx. 3.5kg Plastic packing
18	Cycle Life		800 times
19	Warranty		12 months

All lithium ion battery PACK 22.2V series with 3.7v 2600 mAh 18650 cell as below.

Model	Voltage	Capacity	Size/Weight(package)
SSL-ICR6S1P	24V/22.2V	2.6Ah	4020200mm or Customized
SSL-ICR6S2P		5.2Ah	Recommend or Customized. The Lithium ion battery PACK can packing with PVC/Plastic box/Iron box that size/weight is according to the battery solution.
SSL-ICR6S3P		7.8Ah
SSL-ICR6S4P		10.4Ah
SSL-ICR6S5P		13.0Ah
SSL-ICR6S6P		15.6Ah
SSL-ICR6S7P		18.2Ah
SSL-ICR6S8P		20.8Ah
SSL-ICR6S9P		23.4Ah
SSL-ICR6S10P		26.0Ah
SSL-ICR6S20P		52Ah

Charging Attention	Charging current and charging voltage should be less than specified in the Product Specification.
	The charger shall be designed to comply with Specification.
	It is dangerous that charging with higher current or voltage than Product Specification may cause damage to the cell electrical,mechanical safety performance.

Lithium battery's advantage

Lithium ion batteries are common in consumer electronics. They are one of the most popular types of battery for portable electronics, with one of the best energy-to-weight ratios, no memory effect, and a slow loss of charge when not in use. In addition to uses for consumer electronics, lithium-ion batteries are growing in popularity for defense, automotive, and aerospace applications due to their high energy density.
Lithium batteries are lighter than other equivalent secondary batteries-often much lighter. The energy is stored in these batteries through the movement of lithium ions.
The lithium ion electric bike battery is more safe and reliable than the lead acid one. It does not explode or burn when bump, heavy stress, needle pricking, short circuit, overcharge and overheat. Environment-friendly: Accredited with CE, without any hazardous and noxious substances. compacted in volume and light in weight.

As more and more pollution,Warming seriously,Earth Close to Unfit for human Living.

Previous: 24V 25.2V 9AH Lithium Ion battery pack with built in BMS

Next: 60v 20Ah lithium ion battery pack for E bike

1. Q: Can you accept OEM and ODM Service? What information should be provided for OEM and ODM?

A: Yes, we supply OEM&ODM service as clients requirement.Please provide details in below picture, such as voltage, capacity, max continuous working current, size requirement, package,etc.
